Mechanical Transplanters FPA EVO, FPA MULTIPLA and FP Mulch

Mechanical Transplanters FPA EVO, FPA MULTIPLA and FP Mulch

Transplant onto mulched ground at maximum efficiency!

Mechanical Transplanters FPA EVO, FPA MULTIPLA and FP Mulch Mechanical Transplanters FPA EVO, FPA MULTIPLA and FP Mulch Mechanical Transplanters FPA EVO, FPA MULTIPLA and FP Mulch
FPA EVO
FPA MULTIPLA
FP

FPA EVO

HP 40 ÷ 150

120 ÷ 225 cm / 47" ÷ 88"

30 ÷ 200 cm / 12" ÷ 80"

FPA MULTIPLA

HP 40 ÷ 150

120 ÷ 225 cm / 47" ÷ 88"

23 ÷ 50 cm / 11" ÷ 20"

FP

HP 40 ÷ 150

120 ÷ 225 cm / 47" ÷ 88"

n.d. / n.a.

BOOK YOUR CALL

6.000

plants / hour per row

MAXIMUM PRODUCTIVITY YIELD PER OPERATOR



Mechanical transplanter for transplanting on mulching film for plants in module (diameter from 2 to 5 cm) and square block (side from 3 to 5 cm).

3types of frame

  • Rigid
  • Folding
  • Telescopic
  • Vegetables: tomato, lettuce, brassicas, celery, peppers and all other vegetables having similar leaves with min height 6cm and max 25cm
  • Operators: 1 each row (FPA Evo) and 1 for 2 rows (FPA MULTIPLA)
  • Min row spacing: 30cm (FPA) - 34 cm (FPA with turning carousel) - 23 cm (FPA MULPTIPLA)
  • Main fittings: parallel linkage - water applicators - hydraulic transmission

With FPA Evo and FPA MULTIPLA you can transplant on plastic, paper film and bare ground, in greenhouses or in open fields. The inter-row is adjustable starting from cm. 23.

Both transplanters can be combined with the FP mulcher.

The FERRARI FP film layer extends mulch on the ground in a perfect way. Once the film is set the machine adds ground on the sides by means of ploughshares that are adjustable in height and in width.

FERRARI FP keeps the film constantly in tension by using a front roller that turns together with the film. The film is positioned in contact with the metal roller and rotates freely towards the ground.

Details

FPA EVO

The distance in the row is adjustable form cm 19 to cm 186 (according to the quantity of cups that varies from 1 to 6).

FPA MULTIPLA

It's equipped with a double-row carousel. One operator can set two lines of plants in the ground without any problem.  The row width is adjustable from 23 cm / 9” up to 50 cm / 19.68” (depending on the model version).

The plant spacing can be varied from 18 cm / 7” to 165 cm / 64.96” (according to the number of pincers installed on every unit - from 1 to 6).

FP

The film is positioned in contact with the metal roller and rotates freely towards the ground. In fact the machine does not need any holding shaft nor any clutch to support the plastic roll.

It does an ideal job thank to its simplicity. It works polyethylene, biodegradable film and paper. Single bed and multiple beds versions are available

BOOK YOUR CALL
*}
